HiYi Fast Response High Sensitivity Compact Design USB ATEX Handheld Laser Methane Leak Detector
Z100 Handheld Laser Methane Detector
New One,Much lighter, Much Economic
OVERVIEW
Z100 Laser Methane Detector is like LaserMethane mini (LMm) which is a compact handheld detector for the detection of methane gas at a safe distance (0-100m).
Utilising laser technology, methane leaks are located by pointing the laser beam towards the suspected leak, or along the survey line.
Laser Absorption Spectroscopy technology makes Z100 could avoid interference of unrelated gas and only response for methane leakage.
| Measure Principle | Tunable Semiconductor Laser Absorption Spectroscopy(LDLAS) |
| Detection Objection | Methane (CH4) |
| Static Detection Limitation | 5 ppm*m |
| Response Time | 0.1s |
| Measure Range | 0-99999ppm*m |
| Maximum Detection Distance | 15m |
| Laser for Detection | Class I, eyesafe laser |
| Laser for Indicator | Class II, no direct vision or equipment viewing |
| Protection Lavel | IP54 |
| Explosion Proof | Exib IIA T4 Gb |
| Operation Temperature | -20 ~50 ℃ |
| Humidity | 30~90%RH, no condensation |
| Battery | Li-ion, 8 hours |
| Display | Concentration values |
| Alarm | Voice,Screen Display |
| Size | 13x70x35mm |
| Weight | 0.3 kg |
FEATURES & BENEFITS
1.High Sensitivity
5 ppm*m detection sensitivity.
2.Fast-speed Response
Shortest response time is 0.1 s.Users could set the alarm threshold and review of maximum historical concentration easily.
3.Further Detection Distance
Z100 is a portable device with the maximum detection of 15 meters. It is easy to operate and indicated spot of Z100 could observe clearly out of doors.
4.Intrinsic Safety
Z100 has passed the intrinsic safety certification of Exib IIA T4 Gb.The protection level of Z100 is IP54.
APPLICATION
Laser Methane Detectors for natural gas leak detection remote monitoring of elevated methane gas concentrations in ambient air.
It is specifically designed for the constant scanning and monitoring of mission-critical areas such as compressor stations, gas tanks, storage facilities, tank farms, gas stations, LNG Terminals, city gates and wellheads.
